Vehicle Care 10-11
A. Engine Coolant Surge Tank
and Pressure Cap. See Engine
Coolant on page 10‑21.
B. Engine Air Cleaner/Filter on
page 10‑16.
C. Engine Oil Dipstick. See Engine
Oil on page 10‑12.
D. High Voltage Battery Coolant
Reservoir and Pressure Cap.
See Cooling System (Engine)
on page 10‑18 or Cooling
System (High Voltage Battery)
on page 10‑19 or Cooling
System (Power Electronics
and Charger Modules) on
page 10‑20.
E. Engine Cover.
F. Engine Oil Fill Cap. See Engine
Oil on page 10‑12.
G. Power Electronics Coolant
Reservoir and Pressure Cap.
See Cooling System (Engine)
on page 10‑18 or Cooling
System (High Voltage Battery)
on page 10‑19 or Cooling
System (Power Electronics
and Charger Modules) on
page 10‑20.
H. Brake Fluid Reservoir.
See “Brake Fluid” under
Brakes on page 10‑25.
I. High Voltage Cables
(Orange Color).
J. Remote Positive (+) Terminal.
See Jump Starting on
page 10‑79.
K. Power Electronics Module.
L. Windshield Washer Fluid
Reservoir. See “Adding Washer
Fluid” under Washer Fluid on
page 10‑24.
M. Remote Negative (−) Terminal.
See Jump Starting on
page 10‑79.
N. Engine Compartment Fuse
Block on page 10‑38.
