Vehicle Care 10-43
Fuses Usage
F8 Empty
F9 Empty
F10
Body Control
Module 1/Body
Control Module
Electronics/Keyless
Entry/Power Moding/
Center High Mount
Stoplamp/License
Lamps/Left Daytime
Running Lamp/Left
Front Parking Lamp/
Right Rear Taillamp/
Hatch Release
Relay Control/
Washer Pump Relay
Control/Switch
Indicator Lights
F11
Body Control
Module 4/Left
Headlamp
F12 Empty
F13 Empty
Fuses Usage
F14 Empty
F15
Power Outlet (Inside
Floor Console/Rear
of Floor Console)
F16 Empty
F17 Empty
F18 Empty
Relays Usage
R1
Retained Accessory
Power Relay for
Power Outlets
R2 Empty
R3 Empty
R4 Empty
Diodes Usage
DIODE Empty
Instrument Panel Fuse
Block (Right Side)
The instrument panel fuse block is
on the passenger side end of the
instrument panel. To access the
fuses, open the fuse panel door
by pulling out.
To reinstall the door, insert the
bottom tab first, then push the door
back into its original location.
