Vehicle Care 10-19
Cooling System
(High Voltage Battery)
During vehicle operation and
also during charging, the high
voltage battery cells in the
vehicle are kept within a normal
operating temperature range.
If the temperature rises above this
temperature, the battery cooling
system turns on the air conditioning
compressor and cools the coolant
until the correct temperature is
reached. If the temperature falls
below this temperature, a high
voltage heater, located in the
battery, heats the coolant until the
correct temperature is reached.
What to Use
The high voltage battery coolant
reservoir in the vehicle is filled
with a 50/50 mixture of DEX-COOL
engine coolant and deionized water.
If using this mixture, nothing else
needs to be added.
Checking Coolant
The vehicle must be on a level
surface when checking the coolant
level.
The high voltage battery
coolant reservoir is located
on the passenger side of the
engine compartment. See Engine
Compartment Overview on
page 10‑10 for more information
on location.
Check to see if coolant is visible
in the high voltage battery coolant
reservoir. If coolant is visible but the
coolant level is below the cold fill
line, there could be a leak in the
cooling system.
The high voltage battery coolant
should only be serviced by a
qualified technician.
