Chevrolet Volt Owner Manual - 2011
Vehicle Care 10-47
Fuses Usage
F10
Regulated Voltage
Control/Ultrasonic
Front and Rear
Parking Assist
(If Equipped)
F11 Horn
F12
Rear Power
Windows
F13
Electric Parking
Brake
F14
Rear Defog
(Upper Grid)
Fuses Usage
F15 Empty
F16 Hatch Release
F17 Empty
F18 Empty
Relays Usage
R1
Rear Defog
(Upper Grid)
R2 Hatch Release
R3 Empty
Relays Usage
R4 Empty
R5 Empty
R6 Empty
R7 Empty
R8 Horn
Diodes Usage
DIODE Empty
