R3250Hz Universal Series Technical Manual
108
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Model
COU-36HDR4
COU-36HZDR4
Outdoor power supply
V/Ph/Hz
220~240/1/50
380~415/3/50
Cooling
Capacity
KW
6.6-10.5-12.8 6.6-10.5-12.8
Power input
W
600-3050-3800
600-3050-3800
Current input
A
2.5-19.4
1.5-10
Heating
Capacity
KW
7.35-11.5-13.2 7.35-11.5-13.2
Power input
W
690-3275-4000
690-3275-4000
Current input
A
3-20.4
1.8-10.5
Compressor
Model
KTF310 KTF310
Type
DC/Twin-rotary
DC/Twin-rotary
Brand
GMCC
GMCC
Frequency range
Hz
12-120
12-120
Capacity
W
9435
9435
Input
W
2575
2575
Current(RLA)
A
5.05
5.05
Refrigerant oil
ml
1000 1000
Outdoor fan motor
Model
DR-310-120-8
DR-310-120-8
Power output
W
120
120
Speed
r/min
800 850
Insulation class
E
E
Outdoor coil
Number of rows
2
2
Tube pitch(a) x row pitch(b)
mm
21×13.4
21×13.4
Fin spacing
mm
1.6
1.6
Fin type
Hydrophilic
Hydrophilic
Tube outside dia. and type mm
Φ9.52
Φ9.52
inner grooved inner grooved
Coil length x height x width
mm
1035×750×43.3
1035×750×43.3
Number of circuits
4
4
Outdoor air flow(High speed)
m3/h
4200 4200
Outdoor noise level
power level
dB(A)
68
68
pressure level
55
55
Outdoor unit
Dimension(W*H*D)
mm
1030×788×432
1030×788×432
Packing(W*H*D)
mm
1120×900×485 1120×900×485
Net/Gross weight
kg
68/74
75/81
Refrigerant type/quantity
g
R32/2150
R32/2150
Throttle part
EXV EXV
Design pressure
MPa
4.5/1.6
4.5/1.6
Max pressure
MPa
4.5
4.5
Connection wire
Power wiring
mm2
3×4.0 5×2.5
Signal wiring
mm2
4×2.5
4×2.5
Refrigerant piping
Liquid side/Gas side
mm
Φ9.52/Φ15.88
Φ9.52/Φ15.88
Max. pipe length
m
65
65
Max. high drop
m
30
30
Ambient temp
cooling
°C
-15
～
50
-15
～
50
heating
°C
-15
～
30
-15
～
30
