2. Connect the cables to the unit.
a. Option 1: Standard communications cable.
b. Option 2: Premade RJ-9 quick connector.
3. Attach the wires in the installation box.
Note! Quick installation using an RJ-9 cable or screw terminal.
Copyright © 2021. All rights reserved.
16 (37)
N03104128 Rev. A VariPro Room controller – Installation and Operation Manual
