4. Attach the controller’s bottom plate to the installation box. The attaching
requires opening the front panel. Open the front panel by pushing the Open
button on the bottom of the panel with a thin, pointed object and gently lifting
the bottom edge of the control panel.
Note! Only one controller can be connected to one group of units.
Copyright © 2021. All rights reserved.
17 (37)
N03104128 Rev. A VariPro Room controller – Installation and Operation Manual
