14.0. PREVENTATIVE MAINTENANCE (Cont.):
14.2. CHECKING HIGH PRESSURE PUMP OIL (USING DIPSTICK OR
SIGHT GLASS):
14.2.1. The high-pressure pump oil may be checked by observing the level on the
dipstick attached to the oil fill cap located on top of the pump.
14.2.2. The oil level must be maintained between the full and add marks. If required add
oil (refer to Section 14.3.6.).
Oil Fill Cap/Dipstick
DO NOT ATTEMPT ANY SERVICE ON ChipBLASTER UNIT
WITH POWER ENERGIZED. REMOVE ALL ENERGY
SOURCES AND LOCK OUT / TAG OUT.
OIL FILL CAP
DIPSTICK
!
FAILURE TO USE
MOBIL 1 FULLY-SYNTHETIC 15W-50 WILL
VOID YOUR WARRANTY
!
“
ADD
”
Mark
“
FULL
”
Mark
HIGH-PRESSURE
PUMP
