ChipBLASTER Inc
79
THIS PRINT IS THE PROPERTY OF ChipBLASTER. THIS
DOCUMENT CONTAINS PROPRIETARY INFORMATION AND SUCH
INFORMATION MAY NOT BE DISCLOSED TO OTHERS FOR ANY
PURPOSE OR USED FOR MANUFACTURING PURPOSES WITHOUT
WRITTEN PERMISSION FROM ChipBLASTER.
TITLE:
CUSTOMER:
PO BOX 1057
MEADVILLE, PA 16335
UNIT:
Chip
X.XXX
X.XXXX
X.XX
BREAK ALL SHARP EDGES
REMOVE ALL BURRS &
(NONACCUMULATIVE)
X.X
SIZE:
B
Tolerances
0.0005
0.01
0.005
1/32
BLASTER
USA
BLASTER
www.chipblaster.com
DRAWN BY:
Chip
APPROVED BY: SCALE: DATE:
NTS
FAX: (814)724-6287
PHONE: (814)724-6278
DETAIL
DRAWING NUMBER:SHEET:
OF
PART NO. QTY.
REV:
MAT'L:
DESCRIPTION
REV DESCRIPTION DATE
11/01/00
RA 30011
11
UNIVERSAL STANDPIPE ASSEMBLY
C
8
1
7
4
2
3
9
4
5
°
1 8838 1
STANDPIPE BRACKET
2 6213 1
1 1/2" STREET ELL
3 6059 1
1 1/2" HOSE BARB
42
1 1/2" NPT LOCKNUT
5 6022 1
1" HOSE BARB
6 6107 1
1" ELBOW
71
5/16-24 X 1 1/2" HH BOLT
81
5/16-24 NUT
9
1" X 12" NIPPLE
6249 1
1
5524
0071
0335
B ITEM 6 WAS 1" COUPLING AND ADDED
B
NOTE 1. R.B. 25 FEB. 03
NOTE:
1. TAPE FITTINGS 3, 5 AND 9 - TIGHTEN ALL FITTINGS.
5
6
Ø7.1 (180MM)
Ø6.3 (160MM) B.C.
(4) Ø0.28 (7MM)
HOLES EQ SP
19 JUL 05C ITEM 1 WAS P/N 8830 WPA
1.0 (25MM)
RECOMMENDED
PLACEMENT
MACHINE SUMP
BOTTOM
27.0. OPTIONAL EQUIPMENT:
27.1. MACHINE SUMP STANDPIPE ASSEMBLY (P/N 30011):
27.1
