23.0. FOOTPRINT DRAWING:
23.0
BASE WEIGHT: 550LB (249KG)
SHIPPING WEIGHT: 750LB (340KG)
SHIPPING CONTAINER SIZE (QT'Y 2): 48"W X 67"L X 53"H
W1219MM X L1702MM X H1346MM
ADD FOR:
FLUID (SINGLE FILTER): 22LB (10KG)
FLUID (DUAL FILTER): 44LB (20KG)
NOTE: FLUID WEGHT CALCULATED USING WATER AT 68° 8.3LB (3.8KG)
FLOOR LOADING: BASE WEIGHT + OPTION(S) +FLUID WEIGHT = PSI
28.2744
PSI X .06895 = BAR
FOOTPRINT
D16-70, D20-140-5, D30-80
JRG
JRG
23NOV05
D16 D20 D30 FP
11
AS NOTED
A
1:10
41.87 [1063.5]
14.96 [379.9]
19.69 [500.0]
32.57 [827.4]
MINIMUM SUGGESTED WORKING AREA
31.69 [804.8]
12.00 [304.8]
76.53 [1943.9]
42.43 [1077.6]
36.00 [914.4]
