ChipBLASTER Inc
7
2.0. Table of Contents (Cont.):
Return pump - Check for leaks Section 14.30 Page 33
Return pump - Check inlet and outlet Section 14.31 Page 33
Troubleshooting Section 15.0 Page 34
Troubleshooting flow chart (Figure 3) Section 15.1 Page 35
Pressure adjustment procedure Section 16.0 Page 36
High pressure pump replacement Section 17.0 Page 37
Belt installation Section 18.0 Page 38
Deflection force chart Section 18.5 Page 40
System contamination purging procedure Section 19.0 Page 41
Electrical drawings Section 20.0 Page 43
Mori Seiki Power Interface Section 20.0 Page 51
Mori Seiki Control Interface Section 20.0 Page 52
Daewoo/Doosan Interface Section 20.0 Page 53
Kiwa Interface Section 20.0 Page 54
Schematic piping drawing Section 21.0 Page 59
Mechanical assembly Section 22.0 Page 60
Gauge Panel – Top Section 22.1 Page 60
Control Panel – Front Section 22.2 Page 61
Control Panel – Inside Enclosure Section 22.3 Page 62
Sub Plate Elevation – Left Side Section 22.4 Page 63
Sub Plate Elevation – Right Side Section 22.5 Page 64
Manifold block assembly Section 22.6 Page 65
Filter Assembly Section 22.7 Page 66
Ship Loose Items Section 22.8 Page 67
Spare Parts Section 22.13 Page 68
Footprint drawing Section 23.0 Page 69
Warranty Section 24.0 Page 70
Warranty (limited) – New equipment Section 24.1 Page 70
Warranty (limited) – Used equipment Section 24.2 Page 72
Warranty (limited) – Retrofits Section 24.3 Page 74
Warranty claim form
Section 24.4 Page 76
Warranty registration card
Section 24.5 Page 77
Warranty validation card
Section 24.6 Page 78
Optional Equipment Section 27.0 Page 79
Machine Sump Standpipe Assembly Section 27.1 Page 79
Supplement Data Section 28.0 Page 80
1000 PSI orifice chart Section 28.1 Page 80
2.0
