Freeze-dryer Alpha 1-4 LSCplus
Freeze-dryer Alpha 2-4 LSCplus
5 Set-up and connection
34 / 131
Version 01/2011, Rev. 2.3 of 03/07/2017 • sb
Translation of the original operating manual
Thyracont VCP63 (Pirani)
Pfeiffer CMR 363 (capacitive)
Fig. 15: Vacuum sensors of different manufacturers
NOTE
The vacuum sensor comes supplied in a calibrated state.
After the freeze-dryer has been switched on, the vacuum sensor needs
several minutes until it is ready for operation.
