Freeze-dryer Beta 1-8 LSCbasic
Freeze-dryer Beta 2-8 LSCbasic
10 Technical data
Version 03/2018, Rev. 1.5 of 09/03/2020 • sb-dc
85 / 107
Translation of the original operating manual
Noise level according to DIN
45635
54 dB(A)
54 dB(A)
EMC according to EN 55011
Class B
Class B
Heat emission
0.6 kW min
1.1 kW max
1.1 kW min
1.6 kW max
Equipment connections
Beta 1-8 LSCplus
Beta 2-8 LSCplus
Aeration
Hose nozzle DN6
(outside diameter 10 mm max.)
Hose nozzle DN6
(outside diameter 10 mm max.)
Drain
Hose nozzle DN10
(outside diameter 12 mm)
Hose nozzle DN10
(outside diameter 12 mm)
Vacuum connection
Small flange connection DN25KF
(ISO 28403, DIN 2861)
Small flange connection DN25KF
(ISO 28403, DIN 2861)
Vacuum sensor
SUB D-9
VCP 63
SUB D-9
VCP 63
Option: data interface (LAN)
RJ 45
RJ 45
Special equipment: water
cooling system
Beta 1-8 LSCbasic
Beta 2-8 LSCbasic
Part number
102422
102423
Cooling water consumption
max. 0.16 m
3
/h
max. 0.20 m
3
/h
Heat carried off via the cooling
water
1.1 kW
1.6 kW
Cooling water feed flow connection
R3/4" with hose nozzle DN13
R3/4" with hose nozzle DN13
Cooling water return flow
connection
R3/4" with hose nozzle DN13
R3/4" with hose nozzle DN13
→ 10.1 Umgebungsbeding ungen
10.1 Ambient conditions
→ 10.1 Umgebungsbeding ungen
• Use in closed spaces
• Altitudes up to 2,000 m
• Ambient temperature between +5°C and +25°C
• Maximum relative humidity of 80%
• Mains voltage fluctuations of up to ± 10% of the rated voltage
→
10.2 Technical documentation
The technical documentation of this freeze-dryer (e.g. circuit diagram,
cooling system) and the safety data sheets of the manufacturers (e.g. for
refrigerant) is not attached to this operating manual.
You can order these documents from our service department.
