Christie DHD775-E - PIP;PBP Compatibility

E Series User Manual
020-000515-01 Rev. 2 (03-2013)
6-2
6.2 PIP/PBP Compatibility
Main
PIP/PBP
HDMI 1 HDMI 2
Display-
Port
VGA BNC
Compo-
nent
S-video
Com-
posite
RJ45
USB type
B (mini)
USB
type A
HDMI 1 ● - - ● - ● ● ● ● ●
HDMI 2 ● ● ● ●
DisplayPort - ● - - ● - ● ● ● ● ●
VGA - ● - - ● - ● ● ● ● ●
BNC ● - ● ● - ● - - - - -
Component - ● - - ● - ● ● ● ● ●
S-video ● - ● ● - ● - - - - -
Composite ● - ● ● - ● - - - - -
RJ45 ● - ● ● - ● - - - - -
USB type B
(mini)
● - ● ● - ● - - - - -
USB type A ● - ● ● - ● - - - - -
● : PIP/PBP combinations are enabled
- : PIP/PBP combinations are disabled
Signal
Type
Resolution
Frame Rate
(Hz)
HDMI 1 HDMI 2 VGA
Display-
Port
BNC
Compo-
nent
S- video CVBS
SECAM SECAM (M) 50 ● ●
EDTV
480p 60 ● ● ● ● ● ●
576p 50 ● ● ● ● ● ●
HDTV
1080i 60 ● ● ● ● ● ●
720p 50 ● ● ● ● ● ●
720p 60 ● ● ● ● ● ●
1080p 24 ● ● ● ● ● ●
1080p 25 ● ● ● ● ● ●
1080p 30 ● ● ● ● ● ●
1080p 50 ● ● ● ● ● ●
1080p 60 ● ● ● ● ● ●
