An Overview of the Products
3
V/F
-------- or
--------
I limit
V/F or I limit selection key: In normal mode, the V/F key offers
the user the option of programming voltage or frequency. In shift
mode, this key enables the user to program software rms (root
mean square) limit on the output current.
4
I/P/PF/CF
-------- or
---------
LOCAL
I/P/PF/CF selection key: In normal mode, the user can
repeatedly press this key to select one of the measurement values
to display. In shift mode, this key provides the user with returning
controls from remote PC to front panel keypad.
5
OUT/QUIT
-------- or
---------
EXT PROG
OUT/QUIT command key : In normal operation, pressing of the
key may enable the 6430/6420/6415 output power to the loading
devices. If the user has entered into setup procedures, this key
will be used to quit from present setting routine. In shift mode,
this key enables external programming.
6
SHIFT
Shift mode selection key: Pressing of the key makes the
6430/6420/6415 switch from normal operational mode to shift
mode, or from shift mode to normal mode.
7
1 to 9 ,
0 and y
-------- or
--------
F1 to F9
, LOCK , and
RANGE
Numeric and decimal keys: In normal mode, the user can
program numeric data with the digital keys and the decimal key.
In shift mode, the keys from 1 to 9 save data into or recall
them from memory channels F1 to F9 respectively. Additionally,
In shift mode, 0 enables data lock and configuration setup , and
y offers programming of the full range of output voltage.
8
ENTER The ENTER key is to confirm the setting of parameters.
9
Rotary knob: The user may input programming data or options by
turning the rotary knob to the desired ones.
10
Main Power switch: Power on/off the 6430/6420/6415 by this
switch.
