Programmable AC Source 6430/6420/6415 User‘s Manual
** WARNING **
To protect operating personnel, the wire connected to the GND terminal must be
connected to an earth ground. In no event shall this instrument be operated without
adequate ground connection.
Figure 2-1 Input Connection
2.4 Output Connection
Output power can be connected from the terminal block located on the rear panel of the
instrument through terminals L and N to the load as shown in figure 2-2. For safety, the wires
to the load should be of a sufficiently large gauge to insure that they do not overheat while
carrying the output current.
2-2
