2-20 Installation
3916 Service Delivery Switch Hardware Installation and Start-up Manual
009-3226-001 Standard Revision E
Copyright
©
2013-2015 Ciena
®
Corporation July 2015
3 Orient the left bracket so that the face of the bracket is flush with the front of
the chassis and the upper hole is an upside-down “T” (see Figure 2-4).
4 Using a Phillips screwdriver, attach the bracket to the left side of the chassis
using 2 of the provided screws.
You have installed the mounting brackets on the 3916. You are now
ready to proceed with Mounting the Chassis. Use one of the following
procedures:
– “Mounting the Chassis and Installing Supplemental Ground in a
Frame Installation” on page 2-22
– “Mounting the Chassis (Supplemental Ground not required) in a
Frame Installation” on page 2-24.
