Ciena 3916 DC Standard - Technical Specifications

6-1
3916 Service Delivery Switch Hardware Installation and Start-up Manual
009-3226-001 Standard Revision E
Copyright
©
2013-2015 Ciena
®
Corporation July 2015
Technical Specifications 6-
This chapter summarizes the technical specifications for 3916.
Table 6-1
Specifications
Feature Specification
Power Rating AC System (Single or Dual Power
Input)
100-240 VAC, 50/60 Hz, 2 Amps
DC System (Single Power Input) +/-24 VDC or +/- 48 VDC, 2 Amps max
Power Consumption Maximum Power Consumption 38 W
Connector Types NNI / UNI Ports as follows:
• Ports 1 to 4 speed is 100/1000 Mbps
• Ports 5 and 6 speed is 1000 Mbps
SFP optics
UNI Ports as follows:
• Ports 1 and 2 speed is 10/100/1000
Mbps
RJ-45
Console Port RJ-45 (EIA-561)
