WELDSKILL 100, 135, 150 MIG
2-5
Introduction
2.10 Specifications
Description WeldSkill 100 Mig WeldSkill 135 Mig WeldSkill 150 Mig
Power Source Part Number W1004100 W1004135 W1004150
Cooling Fan Cooled Fan Cooled Fan Cooled
Welder Type Conventional
Transformer
Conventional
Transformer
Conventional
Transformer
Welding Power Source Mass 13 kg 20 kg 20 kg
Dimensions H 300mm x W 180mm
x D 350mm
H 375mm x W 245mm
x D 420mm
H 375mm x W 245mm
x D 420mm
Manufactured to Australian
Standard
AS 60974.6-2006 AS 60974.6-2006 AS 60974.6-2006
Number of Phases 1 1 1
Nominal Supply Voltage 240V ±15% 240V ±15% 240V ±15%
Nominal Supply Frequency 50Hz 50Hz 50Hz
Welding Current Range 28 – 90 Amps 38 – 120 Amps 41 – 130 Amps
Factory Fitted Supply Plug
Rating
10 Amps 10 Amps 15 Amps
Effective Input Current (I1eff) 4.6 Amps 9.7 Amps 11.6 Amps
Maximum Input Current
(I1max)
13 Amps 24.3 Amps 27.2 Amps
Single Phase Generator Re-
quirement
4 KVA 6.5 KVA 7 KVA
Welding Output, 40ºC, 10 min. 90A @ 10%,22.2V 120A @ 10%, 20.0V 130A @ 10%, 20.5V
57A @ 25%, 20.7V 75A @ 25%, 17.8V 82A @ 25%, 18.1V
28A @ 100%, 23.7V 38A @ 100%, 15.9V 41A @ 100%, 16.1V
Protection Class IP21S IP21S IP21S
NOTE
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings,
all capacities, measurements, dimensions and weights quoted are approximate only. Achievable
capacities and ratings in use and operation will depend upon correct installation, use, applications,
maintenance and service.
2.11 Options and Accessories
Description Part Number
WeldSkill Argon Regulator/Flowmeter 210254
WeldSkill Welding Equipment Trolley W4011501
