Service
SECTION 5:
SERVICE
5.01 Routine Maintenance &
Inspection
!
WARNING
There are extremely dangerous voltage and
power levels present inside this product.
Do not attempt to open or repair unless
you are a qualified electrical tradesperson.
Disconnect the Welding Power Source
from the Mains Supply Voltage before
disassembling.
Welding equipment should be regularly checked by a
qualified electrical tradesperson to ensure that:
• Themainearthwireoftheelectricalinstallation
is intact.
• Power point forthe WeldingPower Source
is effectively earthed and of adequate current
rating.
• Plugsandcordextensionsocketsarecorrectly
wired.
• Flexible cord is of the3-core tough rubber
or plastic sheathed type of adequate rating,
correctly connected and in good condition.
• Weldingterminalsareshrouded to prevent
inadvertent contact or short circuit.
• The frame of the Welding Power Sourceis
effectively earthed.
• Weldingleadsandelectrodeholderareingood
condition.
• TheWeldingPowerSourceiscleaninternally,
especially from metal filing, slag, and loose
material. If any parts are damaged for any
reason, replacement is recommended.
5.02 Cleaning the Welding Power
Source
!
WARNING
Refer to WARNING on page 3-2.
To clean the Welding Power Source, open the
enclosure and use a vacuum cleaner to remove
any accumulated dirt, metal filings, slag and loose
material. Keep the shunt and lead screw surfaces
clean as accumulated foreign material may reduce
the welders output welding current.
5.03 Cleaning the Feed Rolls
Clean the grooves in the drive rolls frequently. This
can be done by using a small wire brush. Also wipe
off, or clean the grooves on the upper feed roll. After
cleaning, tighten the feed roll retaining knobs.
CAUTION
Do not use compressed air to clean the
Welding Power Source. Compressed air
can force metal particles to lodge between
live electrical parts and earthed metal parts
within the Welding Power Source. This
may result in arcing between this parts
and their eventual failure.
5.04 Basic Troubleshooting
!
WARNING
There are extremely dangerous voltage
and power levels present inside this
product. Do not attempt to open or
repair unless you are a qualified electrical
tradesperson and you have had training in
power measurements and troubleshooting
techniques.
If major complex subassemblies are faulty, then
the Welding Power Source must be returned to an
Accredited CIGWELD Service Provider for repair.
The basic level of troubleshooting is that which
can be performed without special equipment or
knowledge.
