WELDSKILL 100, 135, 150 MIG
3-17
Installation
3.21 Setup for WeldSkill 150 Mig with Gas Shielded MIG Wire
!
WARNING
Before connecting the work clamp to the work and inserting the electrode wire in the Mig Torch
make sure the Mains power supply is switched off.
CAUTION
Remove any packaging material prior to use. Do not block the air vents at the front or rear of the
Welding Power Source.
NOTE
Refer to the set up guide located on the inside of the wirefeed compartment door.
WORK
WORK CLAMP
ARC
240V AC POWER SOURCE
Polarity Terminal Knobs
Cable to MIG Torch
(Red Cable)
Cable to Work Lead
(Black Cable)
Art # A-09000_AB
Connection for GMAW (straight polarity)
Figure 3-17: Gas Shielded Set-up for WeldSkill 150 Mig
