INTRODUCTION 2-4 0-5461
2.08 Transporting Methods
These units are equipped with a handle for carrying purposes.
WARNING
ELECTRIC SHOCK can kill. DO NOT TOUCH live electrical parts. Disconnect input power conductors from de-energized supply
line before moving the welding power source.
!
WARNING
FALLING EQUIPMENT can cause serious personal injury and equipment damage.
Lift unit with handle on top of case.
Use handcart or similar device of adequate capacity.
If using a fork lift vehicle, place and secure unit on a proper skid before transporting.
2.09 Duty Cycle
The rated duty cycle of a Welding Power Source, is a statement of the time it may be operated at its rated
welding current output without exceeding the temperature limits of the insulation of the component parts. To
explain the 10 minute duty cycle period the following example is used. Suppose a Welding Power Source is
designed to operate at a 15% duty cycle, 90 amperes at 23.6 volts. This means that it has been designed and
built to provide the rated amperage (90A) for 1.5 minutes, i.e. arc welding time, out of every 10 minute period
(15% of 10 minutes is 1.5 minutes). During the other 8.5 minutes of the 10 minute period the Welding Power
Source must idle and allowed to cool.
