0-5461 2-5 INTRODUCTION
2.10 Specifications
Description
WeldSkill 180
Toolbox Plant Part No W1008180
Power Source Dimensions H220mmxW130mmxD340mm
Power Source Mass 5.8 KG
Cooling Fan Cooled
Welder Type Stick and Lift TIG Multi Process Inverter Power Source
Australian Standard AS 60974.1-2006 / IEC 60974-1
Number of Phases Single Phase
Nominal Supply Voltage 240V AC ± 10%
Nominal Supply Frequency 50/60 Hz
Welding Current Range 10 - 180 A
Nominal DC Open Circuit Voltage 78 V
Factory Fitted Supply Plug Rating 15 Amps
Effective Input Current (I
1eff
) refer Note 2 15 Amps
Maximum Input Current (I
1max
) 33.8 Amps
Minimum Single Phase Generator
Recommendation (refer Note 4)
7.6 kW
(9.5 kVA @ 0.8 PF)
STICK (MMAW) Welding Output, 40ºC, 10 min. 180 A @ 20%, 27.2 V
147 A @ 30%, 25.9V
110 A @ 60%, 24.4 V
90 A @ 100%, 23.6 V
TIG (GTAW) Welding Output, 40ºC, 10 min. 180 A @ 40%, 17.2 V
150 A @ 60%, 16 V
115 A @ 100%, 14.6 V
Protection Class IP21S
Table 2-1: Specifications
NOTE 1
Due to variations that can occur in manufactured products, claimed performance, voltages, ratings, all capacities,
measurements, dimensions and weights quoted are approximate only. Achievable capacities and ratings in use and
operation will depend upon correct installation, use, applications, maintenance and service.
NOTE 2
The Eective Input Current should be used for the determination of cable size & supply requirements.
NOTE 3
Motor start fuses or thermal circuit breakers are recommended for this application. Check local requirements for your
situation in this regard.
