2.0 UNPACKING
The machine is delivered in a wooden packing
case. This is due to its dimensions and weight
and avoids the risk of damage to the machine.
All displacements should be done by a forklift
or therefore always by two persons.
Because the gross weight is about 122kg.
To unpack the machine as shown in figure
please follow the instructions below.
FIG 2.1
Remove the four side screws (1) with a 10mm wrench (es. UNI 6763) and remove the cover.
Take the 19mm fork wrench (es. UNI 6736) which is fixed on top of the machine by on adhesive
band.
Remove the crews from the bottom of the case (2) with the 19 wrench.
Having removed the screws the machine can be lifted up and placed on the work table.
This operation should be done with two persons.
Once the machine has been finally positioned, the cellophane can be removed. Open the envelope
which contains the Cd of manual and software and the key for the front cover.
Remove the keyboard and with the above mentioned key open the front cover and remove
the elastic bands which hold the pincer.
Please refer to the next paragraph in order to check all the accessories.
ME 1500 – Operators Manual
