7.1 ERROR MESSAGES AND PROBLEM SOLVING
In case of break down or operator error the machine will show on the display a message stating the
cause of the cycle interruption. The error signal is shown by an error code followed by the
corresponding message. Please consult the table for more information in order to resolve the problem.
After having corrected the error condition press START key on the machine in order to restore the
working state of the Embosser.
CODE
MSG
POSSIBLE SOLUTION
E-00
POWER ON STAND BY
Machine expecting the RESET command.
STATUS – PRESS START
Press START.
E-01
OUT OF CARDS – PRESS
Loader empty. Sensor not seeing plate.
START OR RETRY
Add plate into the Loader. Verify sensor.
E-02
CARD MISFEED – PRESS
The clamp has not grabbed the plate. or sensor defective.
START OR RETRY
Press Feed once more or check the loader and or sensor.
E-03
PUNCH MOTOR ERR –
The punch motor is not running. Timing disc sensor not
CHECK CARD/PR.START
working. Fuse blown. Call the technical assistance
E-04
EMBOSS WHL ERR –
Some dies may be out of position and the drum does not return to
CHECK CARD/PRESS
home position. Adjust the dies and press START. Drum sensor
START
defective.
E-05
X MOTOR ERR-CHECK
Check for defects on the plates. X sensor not working correctly.
CARD/PRESS START
Adjust X total in Mechanical Setup.
E-06
Y MOTOR ERR-CHECK
Clamp error. Too low a Y position. Check for slop in Y movement.
CARD/PRESS START
Check for defects on the plates. Y sensor issue.
E-09
EMERGENCY STOP –
The emergency stop button has been pressed.
PRESS START
Turn the mushroom button clockwise and press start to come back to
the operating mode.
E-10
PAUSE STAMPING –
Lost Mask. Format lost, check job.
PRESS START
Call the technical assistance.
E-13
PUSHER MOTOR ERROR
The pusher motor not returning to home position. Check the plate
– PRESS START
loader is jammed. Pusher Sensor not working. Check 24v.
E-16
USER REJECT CARD –
The user has press the ABORT key while the machine stamps.
PRESS/START
Press START.
E-17
MOVEMENT ERROR –
The left sensor is not functioning correctly.
PRESS START
Check for defects on the plates.
E-28
LOST SEMIPERMANENT
Lost eeprom data on Main Board. Call technical assistance. Not a
DATA – PRESS START
configuration file issue.
E-29
DRUM DATA LOST –
Special Drum corrupted file. Reload drum map.
PRESS START
Call for technical assistance. Drum stored in eeprom, not setup file.
E-30
NO DRUM
Special drum file missing. Load drum file.
CONFIGUARTION –
Call the technical assistance.
PRESS START
E-38
CONFIG.LOST – PRESS
Lost data configuration on machine. Enter config data and retry.
START
E-39
NO CONFIGURATION –
Lost data configuration file. Battery defective. Reload config and
PRESS START AND
check.
CHECK
E-47
PAUSE LOADING –
The machine is in pause while load one plate.
PRESS START
Press START.
E-49
LOAD AREA NOT CLEAR
Not used on this machine. Error for ME1000 style. Photosensor detects
– PRESS START
something in Loader area.
E-50
PAUSE IMMEDIATE –
The front cover is open. Contact switch defective. Check connections.
PRESS START
Close the front cover and press START.
E-51
UNLOADER FULL –
Unloader full. Not used on ME1500
PRESS START
Remove the cards from the unloader unit and press START.
