WarmAir
Model 135 Manual REPAIR PROCEDURES
Page 33 of 43
Replacing the Temperature Sensor
1. Request CSZ repair part.
2. Unplug the unit.
3. Remove exterior top cover and exterior wrap (optional).
4. Remove the header from the control board.
5. Unscrew the locknut to release and remove the sensor fixture.
6. Unscrew the thermistor and remove from unit.
7. Carefully tighten the new sensor back into the blower housing make sure the diamond is
oriented toward the front of the unit and re-secure the header to the control board. Make sure
it is properly secured.
8. Re-secure the sensor fixture around the thermistor using the locknut.
9. Complete installation by reversing above steps.
10. Perform a complete functional test of the unit.
Replacing the IV Pole Clamp
1. Request CSZ repair part.
2. Unplug the unit.
3. Remove the knob.
4. Remove the exterior top cover, the exterior wrap, the thermistor and the internal top.
5. Remove the motor mount to ease access to the I.V. pole screws.
6. Remove the three M4 screws that secure the I.V. pole mount to the back plate.
7. Complete the installation by reversing the above steps.
Replacing the Bed Hook
1. Request CSZ repair part.
2. Unplug the unit.
3. Remove the old hook by loosening the two M4 mounting screws from the back side of the unit.
4. Complete the installation by reversing the above steps
