Model 135 Manual ASSEMBLY DRAWINGS AND PARTS LIST
Page 39 of 43
#
Qty/Unit
Description
44
1
Mounting Plate #2
45
13
Kepnut, M4
46
1
Filter Housing
47
1
Gasket, Filter
48
1
Power Switch, Circuit Breaker, 15A, 100/115V
Power Switch, Circuit Breaker, 7A, 230V
49
1
Exterior Wrap
50
1
Membrane Switch Panel
51
2
Screw, M8 x 12 mm Stainless Steel
52
1
Handle, Plastic Coated
53
1
Top Exterior Cover
54
1
Board, CPU PC
55
-
-
56
4
Nut, Flange, M4 Plastic
57
3
P.C. Board Standoff
58
1
Bracket, Lock
59
1
Rod, Threaded, Stainless Steel
60
1
Wiring Harness, Top 100/115V
Wiring Harness, Top 230V
61
1
Wiring Harness, Base
62
1
6 Foot Hose Assembly
63
1
Knob, Clamping
64
1
Label, WarmAir

135, Decorative
65
1
Label, Specification, 100V
Label, Specification, 115V
Label, Specification, 230V
66
1
Label, Grounding
67
1
Label, No Free Hosing
68
11”
Tubing, Shrinkable, Black, ¼”
69
1
F/W Nylon Washer, 9/64X5/16X.025
70
1
Non-shrink Tubing, .158ID, .423LG
71
1
Hose, Power Cord Holder
72
-
-
73
7”
Fiberglass Sleeving 1/2
74
1
Washer, #8 Internal Tooth, S/S
75
1
Screw, M4 x 6mm
76
7”
Fiberglass Sleeving, 3/8
77
1
Washer, Grounding Lug, Green/Yellow (230V only)
78
1
Grounding Lug (230V only)
79
1
Label, Test Port, 100V & 115V
Label, Test Port, 230V
80
1
Capacitor, 6800MF
81
1
Bottom Foam Gasket
82
1
Intake Baffle
83
4
Shoulder screw
84
1
Sensor Fixture
85
1
6MM Hex, Female-Female Standoff, M4
86
1
O-Ring, Buna N, 1.5MM x 3MM ID
87
1
Switch, 135 Deg. Thermal, WA 135
88
1
UDI GTIN Barcode Label
