Chapter 5
Applying Formats for Data Editin
g
Editing Format for Interleaved 25
*Apply
Do Not Apply
Editing Format for Matrix 25
*Apply
Do Not Apply
Editing Format for MSI
*Apply
Do Not Apply
Editing Format for Plessey
*Apply
Do Not Apply
Editing Format for Telepen
*Apply
Do Not Apply
136
138
Table of Contents
