Selecting Output Interface
2.1.1 ACTIVATE KEYBOARD WEDGE & SELECT KEYBOARD TYPE
Once Keyboard Wedge interface is activated, a keyboard type must be selected to
complete the setting.
Activate Keyboard
Wedge & Select
Keyboard Type…
1) Read the aforelisted barcode to activate Keyboard Wedge.
2) Read the “
Decimal Value” barcode on page 153 to select the keyboard type. Refer to
the table below for the corresponding number
3) Read the “Validate” barcode on the same page to complete this setting.
Keyboard Type
By default, the keyboard type is set to PCAT (US). The following keyboard types are supported –
No. Keyboard Type No.
Keyboard Type
1 PCAT (US) 18 PS55 001-3
2 PCAT (French) 19 PS55 001-8A
3 PCAT (German) 20 PS55 002-1, 003-1
4 PCAT (Italian) 21 PS55 002-81, 003-81
5 PCAT (Swedish) 22 PS55 002-2, 003-2
6 PCAT (Norwegian) 23 PS55 002-82, 003-82
7 PCAT (UK) 24 PS55 002-3, 003-3
8 PCAT (Belgium) 25 PS55 002-8A, 003-8A
9 PCAT (Spanish) 26 IBM 3477 Type 4 (Japanese)
10 PCAT (Portuguese) 27 PS2-30
11 PS55 A01-1 28 IBM 34XX/319X, Memorex Telex 122 Keys
12 PS55 A01-2 (Japanese) 29 User-defined table
13 PS55 A01-3 30 PCAT (Turkish)
14 PS55 001-1 31 PCAT (Hungarian)
15 PS55 001-81 32 PCAT (Swiss)
16 PS55 001-2 33 PCAT (Danish)
17 PS55 001-82
To Next Page
