User Guide
5.4 CONFIGURING FORMAT — DEFINE DATA FIELD
5.4.1 START POSITION
Data can be divided into fields in one of the following direction –
from head (F1) to tail (F5)
from tail (F1) to head (F5)
*From Head
From Tail
5.4.2 FIELD ADJUSTMENT
You may apply equal length to all fields, if necessary. If data is found longer than
specified, it will be truncated automatically. When data is found shorter, it will add
“Space” (0x20) to field.
*No adjustment
Set length to adjust
fields… (*0)
1) Read the barcode above to adjust field by length.
2) Read the “
Decimal Value” barcode on page 153 for the desired field length.
3) Read the “Validate” barcode on the same page to complete this setting.
To Next Page
