80
Enter Setup
1500 Barcode Scanner
User Guide
3.14 ITALIAN PHARMACODE
Enable
*Disable
3.14.1 TRANSMIT CHECK DIGIT
Decide whether to include the check digit in the data being transmitted.
*
Transmit
I
talian Pharmacode
Check Digit
Do Not Transmit
91
93
Table of Contents
