Chapter 3
Changing Symbology Settings
3.16.2 GS1 DATABAR OMNIDIRECTIONAL (RSS-14)
Enable
RSS-
1
4 &
RSS Expanded
(Groups I, II)
*Disable
The settings below appl
y to
Group I symbologies only:
GS1 DataBar Omnidirectional
GS1 DataBar Truncated
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
Transmit Code ID
Decide whether to include the Code ID
in the data being transmitted.
*Transmit RSS-14
Code ID
Do Not Transmit
Transmit Application ID
Decide whether to include the Appli
cation ID ("
01
") in the data being transmitted.
*Transmit RSS-14
Application ID
Do Not Transmit
