89
Update
Chapter 2
Selecting Output Interface
2.7 DIRECT USB VIRTUAL COM (1661 MEMORY MODE ONLY)
Only 1661 supports “Direct” USB Virtual COM interface for memory mode. Use the
provided USB cable to connect 1661 to the USB port of PC. You may run
HyperTerminal.exe on your computer, and the scanned data will be transmitted to the
computer. Refer to
1.2.2 Memory Mode.
Note: If you are using USB Virtual COM for the first time, you must install its driver from
the CD-ROM. Driver version 5.3 or later is required. Please remove older versions!
2.7.1 ACTIVATE USB VIRTUAL COM
*Activate Direct
SB
Virtual COM
2.7.2 INTER-FUNCTION DELAY
By default, the inter-function delay is set to zero. Specify a value, ranging from 0 to 254,
to match the computer response time of the keyboard interface. Such delay time is
inserted between every function code (0x01 ~ 0x1F) being transmitted. The longer the
delay time is, the slower the transmission speed will be.
Value
Delay Time Value Delay Time
0 Disable 195 ~ 204 200 millisecond
1 ~ 14 10 millisecond 205 ~ 214 210 millisecond
15 ~ 24 20 millisecond 215 ~ 224 220 millisecond
25 ~ 34 30 millisecond 225 ~ 234 230 millisecond
35 ~ 44 40 millisecond 235 ~ 244 240 millisecond
45 ~ 54 50 millisecond 245 ~ 254 250 millisecond
… …
Inter-Function
Delay… (*0~254)
1) Read the barcode above to specify the inter-function delay.
2) Read the “
Decimal Value” barcode on page 217 for the desired inter-function delay
(millisecond).
3) Read the “Validate” barcode on the same page to complete this setting.
To Next Page
