212
Enter Setup
1660 Barcode Scanner
User Guide
EXAMPLE
Without using the scanner to read the above setup barcodes for configuring the 3610
dongle, you may run HyperTerminal.exe on the host computer to send serial commands
to 3610 via USB Virtual COM.
1) Connect 3610 to the USB port of PC.
2) The Communication LED will indicate when 3610 can accept serial commands after
initializing. Refer to the table below.
If the output interface is USB Virtual COM, run HyperTerminal.exe on your
computer. While the Communication LED on 3610 is purple (red with flashing
blue), type the serial command within 3 seconds.
If the output interface is USB HID, press the “Num Lock” or “Caps Lock” key via
the keyboard 5 times within 3 seconds while the Communication LED on 3610 is
flashing red and blue. This will change the interface from USB HID to USB Virtual
COM and the Communication LED will become purple (red with flashing blue).
Then, run HyperTerminal.exe on your computer. While the Communication LED on
3610 is purple (red with flashing blue), type the serial command within 3 seconds.
After configuring via serial commands, the interface will be reset to USB HID after
re-connecting 3610.
Communication LED Meaning
--- Blue,
solid
Initialize
Red,
solid
Blue,
flashing
Serial command mode with USB Virtual COM: wait 3 seconds for starting a
serial command
Red,
flashing
Blue,
flashing
Serial command mode with USB HID changed to USB Virtual COM first: wait
3 seconds for pressing [Num Lock] or [Caps Lock] 5 times via keyboard
