Chapter 4
Changing Symbology Settings
4.13 FRENCH PHARMACODE
Enable
*Disable
4.13.1 TRANSMIT CHECK DIGIT
Decide whether to include the check digit in the data being transmitted.
*
Transmit
F
rench Pharmacode
Check Digit
Do Not Transmit
