114
Enter Setup
1660 Barcode Scanne
r
User Guide
4.3.2 VERIFY CHECK DIGIT
Decide whether t
o verify the check digit. If in
correct, the barcode will
not be accepted.
Verify
I
nterleaved 25
Check Digit
*Do Not Verify
4.3.3 TRANSMIT CHECK DIGIT
Decide whether to include the check digit in the data being transmitted.
*Transmit
I
nterleaved 25
Check Digit
Do Not Transmit
127
