Chapter 2
Selecting Output Interface
Alphabets Transmi
ssion
By default, the alphabets transmission is case
-sensiti
ve, meaning that the alphabets will
be
transmitted according to th
eir original case, the stat
us of Caps Lock on the
keyboard, as well as the
Capital Lock setting. Select [Ignore Case] to have alphabets tran
smitted according to the status of
Caps Lock on the keyboard only.
Ignore Case
*Case-sensitive
R
efer to 5.1 Letter Case.
88
90
