124
9700 Mobile Computer (CE) Reference Manual
SAVING PREFERENCE CHANGES
After making changes to preference settings, tap Apply. A warning dialog will show
reminding that for the settings to take effect, you will need to restart Bluetooth power.
Proceed to perform a Bluetooth power cycle as in
Turn On/Off Bluetooth
.
BT-CONNECT TAB
The BT-Connect tab allows configuration of the “BT-Connect window”, which can be
opened by tapping the Bluetooth icon
on the taskbar.
Setting
Description
Minimize BT-Connect Select to have the BT Connect window minimized on the taskbar
after it is launched to continue providing Bluetooth services.
Show icon on taskbar
Select whether to display the Bluetooth icon
on the taskbar when
BT Connect is running.
Enable power save Select whether to maintain Bluetooth connections in low power
consumption mode until a profile becomes active.
Tap to save changes
Tap to restore default settings

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
