CipherLab 9700 User Manual

128
9700 Mobile Computer (CE) Reference Manual
4.1. CONTROL PANEL
To access control panel settings:
 Tap Start | Settings | Control Panel to display a window listing all the programs
installed on the mobile computer.
Icon
Description
BACKLIGHT SETTING
Sets screen and keypad timeout and brightness. Four tabs are featured – Brightness,
Battery Power, External Power, and Profile. See also Power
for setting up power
plans to save battery consumption.
Tabbed Page
Description
Brightness Selects whether to allow manual adjustment of the screen and
keypad backlights.
 Adjust the screen to the dimmest comfortable brightness to
save power. See also Adjust Backlight
.
Battery Power Sets the screen backlight timeout on battery power and whether to
trigger screen/keypad light-up upon pressing a key.
Option Default Settings
Turn off LCD backlight if device is not used
for:
Checked;
1 min
Turn off keypad backlight if device is not
used for:
Checked;
5 sec
Turn on LCD backlight when a button is
pressed or the screen is tapped
Checked

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
