9700 Mobile Computer (CE) Reference Manual
1.8.5. 1
ST
USB SYNC
This section will guide you through USB syncing. To connect ActiveSync using USB:
1) Download the right syncing tool as described in Syncing Tools
and install it on your PC.
2) Connect the mobile computer and your PC as described in Use Snap-on Cable
.
3) On your PC, run the syncing program.
ActiveSync should detect the mobile computer. Sync Setup Wizard launches and
prompts to set up Sync Partnership
between two computers.
4) Press Next for “Synchronization Relationship”, or press Cancel for “Temporary
Relationship” if you don't plan to connect to the PC on a regular basis.
If you have pressed Next, follow the on-screen instructions and select the data
categories you would like to synchronize. Once confirmed, synchronization will begin
shortly, and when the process is finished, ActiveSync window will show “Synchronized”
to indicate that the data on the mobile computer and PC are identical.
OR
If you have pressed Cancel, Microsoft ActiveSync opens showing “Guest” and
“Connected”. The mobile computer and the PC are connected but the data is not
synchronized.
A “Synchronization Relationship”
is established between the mobile
computer and the PC

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
