CipherLab 9700 User Manual

51
Chapte
r
1 Use Mobile Compute
r
1.9. VOLUME AND AUDIO
1.9.1. AUDIO PLAYBACK
Use a headset for audio playback and hands-free telephone communication.
The headset jack (3.5 mm DIA) is built up on one side of the mobile computer and sealed
with a hinged rubber. Open the rubber to reveal the headset jack. Plug the connector of
your headset to the jack.
Bluetooth headsets are also supported to deliver better mobility. See Use Bluetooth
.
Figure 12: Audio Playback
1.9.2. VOLUME CONTROL
The mobile computer features an on-screen volume gauge to control the system volume,
including event sounds, notifications and media playback.
1) Tap Start | Settings | Control Panel | Volume
& Sounds.
Volume & Sounds Properties window opens
showing a slider to adjust system volume and a
few checkboxes to select the occasions to play
system sounds for.
2) Adjust the settings to meet your needs.
When finished, tap OK on the title bar to apply
the settings.
Slider bar and buttons to
adjust system volume
Checkboxes to select when
to play system sounds
Headset jack

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
