9700 Mobile Computer (CE) Reference Manual
MEDIA PLAYER
Audio/video file player.
MICROSOFT WORDPAD
Wordpad for entering text.
REMOTE DESKTOP CONNECTION
Program for connection to a remote computer.
SIGNATURE
Signature application which is available for C++ programming via API deployment. See
the CP60 C++ Programming Guide for details.
SIGNATUREDOTNET
Signature application which is available for .NET programming via API deployment. See
the CP60 .NET Programming Guide for details.
SUMMIT CLIENT UTILITY
Utility which controls Wi-Fi connection, adjusts settings and performs diagnostic tests.
TERMINAL EMULATION
Terminal emulation application allows the mobile computer to act as a telnet client and
connect to a host computer to use the applications running on it. See the Terminal
Emulation User Guide for details.
TRANSCRIBER
Application for handwriting recognition.
WINDOWS EXPLORER
Browser for the mobile computer’s internal storage.
2.2.2. SWITCH BETWEEN ACTIVE TASKS
To switch between the active tasks currently running on the mobile computer, tap on
the Taskbar
. In the pop-up menu that shows up, tap the program or task button to open, or
tap Desktop to minimize the active window and display the desktop.
2.2.3. EXIT A PROGRAM
To ensure efficient use of the memory, you should exit a program when it is no longer in use
Note: Always remember to save the data or settings before you exit a program.
Tap to close an active window, dialog box, or running program. You may alternatively
press ESC on the physical keypad to close a dialog box or running program.
Tap
to save the current settings and close a dialog, program, or minimize the window
for certain programs. You may alternatively press Enter on the physical keypad to save
settings and close a dialog or program.

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
