142
9700 Mobile Computer (CE) Reference Manual
ENVIRONMENTAL CHARACTERISTICS
Temperature
Operating
Note
-20 °C to 50 °C / -4°F to 122°F
Storage
-30 °C to 70 °C / -22°F to 158°F (without battery)
-30 °C to 60 °C / -22°F to 140°F (with battery)
Charging
0 °C to 35 °C / 32°F to 95°F (with battery)
Humidity
Operating 5% to 95%, non-condensing (Max 60°C / 140°F)
Storage
5% to 95%, non-condensing (Max 60°C / 140°F)
Resistance
Impact Resistance Multiple 1.8 m (5.9 ft.) drops to concrete, meets and exceeds applicable
MIL-STD 810G specifications
Tumble Test 500 tumbles (1,000 drops) at 1 m (1.6 ft) and 1,000 tumbles (2,000
drops) at 0.5 m (0.8 ft.) per applicable IEC tumble specifications
Splash/Dust Resistance IP65 per applicable IEC 60529 sealing specs
Electrostatic Discharge ± 15 kV air discharge, ± 8 kV contact discharge
Note: CipherLab will not be held responsible for the mobile computer’s malfunction incurred by the
operation outside operating temperature range.
PROGRAMMING SUPPORT
Development Environment & Tools
Integrated Development Environment Visual Studio 2008
Visual Studio 2005
Microsoft SDK Software Development Kit
System API (DLL) for system configuration
Reader API (DLL) for reader configuration
Software & Utilities
CipherLab software package
Reader Config
Button Assignment
Signature Capture
Push to Talk
AppLock
MIRROR Browser for web application
Terminal Emulation
