CipherLab 9700 User Manual

34
9700 Mobile Computer (CE) Reference Manual
Screen Rotation window opens with three orientation modes to select from and an
option to suspend the mobile computer when the screen is facing down.
2) Tap the modes that you wish to enable. The tapped item will light up to indicate it is
currently enabled.
3) Tap OK on the title bar to apply the changes.
The mobile computer will then automatically switch between the enabled modes
according to its physical orientation. For instance, if Portrait and Landscape modes
are enabled, the touchscreen will switch between upright and sideways view according
to the user’s holding position. However, if only Portrait (upright) mode is enabled, the
touchscreen will stay in upright mode regardless of the mobile computer’s orientation.
Three screen orientation
modes
Allows mobile computer to
enter suspension when
facing down
Tapped items will light up

CipherLab 9700 Specifications

General

Battery voltage	3.7 V
Battery capacity	3600 mAh
Battery life (max)	13 h
Display diagonal	3.5 \
Touchscreen type	Resistive
Display resolution	640 x 480 pixels
Flash memory	4 GB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	SD, SDHC
Processor family	OMAP 3730
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
GPS (satellite)	-
Operating system installed	Windows Embedded CE 6.0 R3
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Security algorithms	WEP, WPA, WPA-EAP, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-EAP, WPA2-PSK
Built-in camera	No
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoHS, REACH, WEEE, ErP, BSMI, NCC, SRRC, CCC, ANATEL, RCM
Product color	Black, Yellow
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65

Weight and Dimensions

Depth	47 mm
Width	87 mm
Height	214 mm
Weight	447 g
