24
No. Description No. Description No. Description
1. Power Button 8. Volume Up Button 15. Battery with Battery Cover
2. Status LED 9. Scan Window 16. NFC Detection Area
3. Touchscreen 10. Function Key 17. Hand Strap Hole
4. Microphone & Speaker 11. Side-Trigger (Right) 18. Charging & Communication Pins
5. USB-C Port with Cover 12. Battery Cover Latch 19. Receiver
6. Side-Trigger (Left) 13. Front Camera 20. Rear Camera
7. Volume Down Button 14. Hand Strap Cover
