Circutor Raption Series Service Manual

Raption
102 Service Manual
B
Raption 50 HV /Raption 50 EVO /Raption 100
GENERAL DATA
Display HMI 8" colour antivandal touch screen
Lights for status indication RGB Colour indicator
RFID system
ISO / IEC 14443-1/2/3
MIFARE Classic
MECHANICAL DATA
Enclosure rating IP54 / IK10
Enclosure material Stainless steel
Enclosure acces Frontal key locked door
DC Cable length
CCS 3 meters
CHAdeMO 3 meters
AC Cable length 3 meters
Socket protection Locking System
Weight 235 kg
Dimensions (D x W x H) 355 x 940 x 1800 mm (Without cable engaged)
STANDARDS
IEC 61851-1; IEC 61851-23; IEC 61851-21-2; CE / Combo-2; CHAdeMO compatible; CCS (DIN 70121;
ISO 15118)
CONNECTIVITY
Ethernet 10/100BaseTX
Interface protocol OCPP 1.5 or OCPP1.6J
Wireless Comunication EU 4G LTE / WiFi Hotspot / GPRS / GSM
ENVIRONMENTAL CONDITIONS
Operating temperature -30ºC ... +50ºC
Storage temperature -40ºC ... +60ºC
Operating humidity 5% ... 95% Non-condensing
Sound level in operation < 55 dB
Cooling system Air cooling fans
