Circutor Raption Series - Components Overview

Service Manual 11
Raption
C
Components Overview
Inside the Charge Point it is possible to differentiate four main parts. In the upper part
there are the electronic boards, the electrical protections and the electrical actuators.
In the medium part there are the power modules. In the lower part there is the power input
supply section and the last important part is in both doors.
Electronic boards, etc
Power modules
Power supply section
Right door
Left door
