Circutor Raption Series - Dashboard Overview

Service Manual 53
Raption
D
AC meter
The three-phase electrical energy meter for AC side, measures current and voltage that
is supplied to the AC socket. The meter has RS485 communications with the Screen A1.
This meter is a CEM C21.
Electrical scheme
