Raption
Protection devices
B
RCD
Composed by a compact system that includes a current transformer and differential
relay that activates when current leakage is detected.
There are two of them installed, one in the AC circuit and another one in the DC circuit
(before the AC/DC converters).
RCDs are type B.
