Raption
Maintenance
The maintenance plan is based in years from start-up, hours of charging or standby,
and cycles of charging. Depending of the group of components, is necessary to apply a
specific maintenance period. Check the periods in the next table:
Raption WearCheck list, Key: I → Inspection, R → Replace, - → No maintenance needed
Years from start-up
6 months /
2K cycles
1 year /
4K cycles
2 years/
8K cycles
3 years /
12K cycles
4 years /
16K cycles
5 years /
20K cycles
Estimated time (hours)
for replacement
General maintenance
Preventive maintenance
I I I I
I I
1,5
Control devices
Screen ensemble Raption
-
I I I I R 0,3
Connectors and sockets
Type 2 Connector -
I I R I I 0,75
CCS Connector -
I I R I I 0,75
CHAdeMO Conector -
I I R I I 0,75
Power
Power modules
-
I I I I R 0,25
Extra power supply
I I R I R I 0,15
Contactors and relays
Switching contactors -
- I - I R 0,5
Switching relays -
- I - I R 0,15
Power contactors/relays -
I R I R I 2
Ventilation and heating
Control part fans -
I I R I I 1,5
Power part fans -
I I I I R 1
Filters
- R R R R R 1
Isolation top hat seal
- R R R R R 0,5
